POJAČALO RCF AM1064

Opis

SPECIFICATIONS
Amplifier specifications
NUMBER OF CHANNELS:
1

POWER OUTPUT PER CHANNEL (@ 4 OHM):
60 W RMS

POWER OUTPUT (@ 100 V):
60 W RMS

FREQUENCY RESPONSE (-3DB):
60 Hz ÷ 15 kHz

DISTORTION (THD+N) @ 1 KHZ NOMINAL POWER:
<1.5 %
Input section
BALANCED:
3

GENERAL PURPOSE INPUTS (GPI):
1

LINE CONNECTORS:
RCA

LINE INPUTS:
2

MIC+LINE CONNECTORS:
RCA, XLR

MIC+LINE INPUTS:
3

MIC+LINE PHANTOM:
18 V DC

VOX: (MIC+LINE):
Yes

MONO:
4

STEREO:
2

TOTAL NUMBER OF INPUTS:
5

UNBALANCED:
5
Output section
SIGNAL OUTPUT NUMBER:
1

SIGNAL OUTPUT CONNECTORS:
RCA

POWER OUTPUT CONNECTORS:
Euroblock
Processing
TONE CONTROLS:
Yes
Controls
CONFIGURATION:
Front panel

PRIORITY:
Yes
Protections
COOLING:
Convection

SHORT CIRCUIT:
Yes

THERMAL:
Yes

DC DELAY:
Yes

FUSES:
Yes
Power requirement
OPERATING VOLTAGE:
220-240/115 V~ 50/60Hz

VOLTAGE SELECTION:
External

DC POWER:
Yes

DC POWER VALUE:
24 V

POWER CONSUMPTION:
170 W
Standard compliance
CE MARKING:
Yes
Physical specifications
CABINET/CASE MATERIAL:
Metal

COLOR:
Black

RACK MOUNTING:
19″, 2U
Size
DEPTH:
385 mm / 15.16 inches

HEIGHT:
88 mm / 3.46 inches

WEIGHT:
5.6 kg / 12.35 lbs

WIDTH:
431 mm / 16.97 inches
Shipping informations
PACKAGE DEPTH:
380 mm / 14.96 inches

PACKAGE HEIGHT:
165 mm / 6.5 inches

PACKAGE WEIGHT:
6.72 kg / 14.82 lbs

PACKAGE WIDTH:
500 mm / 19.69 inches

Brand

RCF

RCF je renomirani italijanski brend audio opreme, osnovan 1949. godine u Italiji. Lider je na tržištu live PA uređaja i zvučnika a pored njih, proizvode i pojačala, komercijalna i kućna audio rješenja, miksete, evakuacione sisteme, konferencijske sisteme... Amedex D.O.O. je ovlašteni distributer za RCF proizvode za Bosnu i Hercegovinu.
